| Plating type | Single metal pating layer | Composite multiple plating layer | Alloy plating layer | Multi-layer nickel |
| Cr,Ni,Cu, Zn,Sn,Ag, Au,Cd,Co, Pb etc. | Cr/Ni/Cu etc. | NiP,ZnNi, SZn,SPb etc. | The thickness of each layer of multilayer nickel and the potential difference between nickel layers |
| Substrate | Metal | Non-metal |
| Steel,copper,copper alloys, die-cast zinc,aluminum etc | Plastic,neodymium iron boron,ceramics etc |
| Measuring range | 0.03～300μm |
| The best use range 0.03～50um,Over 50um,the error will gradually become larger |
| Resolution | 0.01um |
| Repeatability | ≤5% |
| Indication error | ≤10% |
| Potential range | 0～3000mv |
| Potential accuracy | 0.01mv |
| Probe size | Standard:φ2.4,φ1.7(unit:mm)
Optional:φ1.2,φ1.0,φ0.8(unit:mm) |
| Wire test | Diameter 0.050～4mm
multi-layer coating thickness on the cylindrical surface, without conversion, direct reading |
| Test stand | Standard:STD07
Optional:STD16,STD19,STD-W wire test stand |
| Calibration | Factory calibration
calibrate a single coating with calibration foils or uniformly calibrate |
| Stop measurement | Automatic judgment |
| Stand-alone use | When not measuring the potential difference |
| Print | A laser or inkjet printer can be purchased separately to print A4 format test results, Excel format, content can be customized
In stand-alone use, a thermal printer can be used to print the test results |
| Print Content | Plating type, single measurement value, average value, maximum value, minimum value, standard deviation, coefficient of variation, time
Thickness-potential curve |
| Display mode | Online use:PC Screen display
Stand-alone use:126*64 dot LCD screen |
| Data stroage | PC Database |
| Test Hot Key | Stand-aone use,you can customize the hot key for single plating or multiple plating/substrate combination |
| Curve Analysis | can be displayed on the same screen and modified at will |
| Pause test | For thick coatings, you can pause at any time and continue the test after changing the electrolyte |
| Data check | multiple query methods |
| Operating system | Win dows XP,win7,win10 |
| Software upgrade | New products in December 2019, continuous upgrade |
| Power Supply | AC 220V, AC 110V can be customized |
| Host Size | 200*255*161(mm) |
